Table 4
Study of different ligands and its effect on the wake concentration.
| Name (*see Appendix) | No coligand | Ligand 1 | Ligand 2 | Ligand 3 | Ligand 4 | Ligand 5 |
|---|---|---|---|---|---|---|
| – | oda | ida | edda | edta | hedtra | |
| Bubble representation |
|
|
|
|
|
|
| Speed where picture was taken | 0.30 m s−1 | 0.28 m s−1 | 0.29 m s−1 | 0.29 m s−1 | 0.28 m s−1 | 0.28 m s−1 |
| Size | 2.8 mm | 2.8 mm | 2.8 mm | 2.8 mm | 2.9 mm | 2.7 mm |
| Camera | Imaging Solutions NX-8S2 | |||||
| Lens | Tamron Makro 100 mm f2, 8 with “C for Nikon” – Adapter | |||||
| Filter | TECHSPECH Blue M55.0 × 0.75 imaging filter | |||||
| Aperture | f8 | |||||
| Exposure time | 2.4 × 10−5 s | |||||
| Frames per second | 4000 fps | |||||
| Focus length | 0.4 m | |||||
| Temperature | 23 ± 1 °C | |||||
