Comparison between the textures of a) a 2D projection of a 3D simulation of microstructure formed with platelets, b) a simulated TEM image based on the 2D projection with background noise, and c) an experimental TEM image of sample 2. The microstructure volume is 65 × 65 × 70 nm3, where 70 nm is the thickness along the projection direction.
