Figure 16

Download original image
Expected, ensemble average values of the coefficient (fraction) of oil fragmentation, fOF, (or interfacial saturation) for different values of the capillary number, Ca, flow rate ratio, r, and viscosity ratio, . Arrows indicate increasing Ca values: →10−8 ≤ Ca ≤ 10−4 and - - - -> 4 × 10−7 ≤ Ca ≤ 10−4.
